Chapter 1- Hardware Description

1-8

The following items appear on the RMX 2000 rear panel:

Table 1-3 RMX 2000 Rear Panel - RTM IP Component Description

Function Name Description

LAN 1 NA - Disconnected.

LAN 2 Used for the Network connection.

LAN 3 For Remote Access only using the Permanent

Management Network. For more information, see the

RMX 2000 Administrator’s Guide, Appendix F:

"Permanent Management Network” on page F-1.

10/100 ShMC NA - For debugging purposes only.

Serial NA - For debugging purposes only.

USB USB key connection. For more information, see the RMX

2000 Getting Started Guide, "First Time Installation and

Configuration” on page 2-1.

Standby button Toggle between CPU activation and standby
